• OILP Planetary Drives

Product features

1.OILP series reducers are driven by NGW two or three gears for high efficiency transmission and low noise operation.

2. The output shaft adopts a combination of high strength bearings to withstand the axial and radial forces transmitted from the outside.

3. The design has a variety of deceleration ratio, through the displacement of the configuration, to achieve a variety of torque and speed choice.

4. The whole gear ring design, small radial size, compact structure, reduce the installation space.

5. Good lubrication and heat dissipation design, the reducer can run stably for a long time.

• Range of application

  Can be used in small mining, agricultural machinery, sheet metal machinery, coal mining machinery thickener and other equipment.
